This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KDLFLaughlin Afb

Private use. Permission required prior to landing.

Laughlin AFB, Texas, United States (78843)

Radio Freq.

Runways

Charts

Lat/Lng:	29° 21' 33.82" N / 100° 46' 40.49" W 29.359394 / -100.777914
Elevation:	1081'ft / 329mMSL
Declination:	E007°
ID / ICAO:	KDLF
FAA:	DLF
Runways:	3
Longest:	13C-31C Asphalt 2,704m / 8,870ft

Airport use:	Military, Private, Permission required
Controlled:	Yes

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

ATIS:	114.4
Clearance Delivery:	120.5
Ground:	138.75
Tower:	114.4, 125.2
Approach:	119.6
Departure:	119.6

[ Edit disabled ]

Nearby VORs <50NM

LAUGHLIN VORTAC		0.4 NM
DLF	freq: 114.40	E 74°

Nearby NDBs

LA FONDA RANCH NDB		14.0 NM
BRX	freq: 269	SE 138°
SPOFFORD NDB		25.8 NM
PFO	356	SE 125°

Runway 13C / 31C

Dimensions:	2703.7 x 45.7m 8870' x 150'ft
Surface:	Asphalt
Edge Lights:	High intensity

	Runway 13C [A]	Runway 31C [B]
Heading:	128°MH 135°TH	308°MH 315°TH
Lat: Lng:	29° 22' 2.83"N 100° 47' 16.47"W	29° 21' 0.39"N 100° 46' 6.28"W
ALS:	ALSF-I
TDZ:	Yes, lighted

[ Edit disabled ]

Runway 13L / 31R

Dimensions:	2526.7 x 45.7m 8290' x 150'ft
Surface:	Asphalt
Edge Lights:	High intensity

	Runway 13L [A]	Runway 31R [B]
Heading:	128°MH 135°TH	308°MH 315°TH
Lat: Lng:	29° 22' 5.6"N 100° 47' 3.73"W	29° 21' 6.94"N 100° 45' 57.79"W

[ Edit disabled ]

Runway 13R / 31L

Dimensions:	1899 x 45.7m 6230' x 150'ft
Surface:	Asphalt
Edge Lights:	Medium intensity

	Runway 13R [A]	Runway 31L [B]
Heading:	128°MH 135°TH	308°MH 315°TH
Lat: Lng:	29° 21' 56.94"N 100° 47' 17.77"W	29° 21' 12.96"N 100° 46' 28.33"W

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

WEBOX FOUR

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

HI-ILS OR LOC/DME RWY 13C	HI-ILS OR LOC/DME RWY 31C	ILS OR LOC/DME RWY 13C	ILS OR LOC/DME RWY 31C	RNAV (GPS) RWY 13C
RNAV (GPS) RWY 31C	RNAV (GPS)-B	VOR/DME RWY 13C	VOR/DME RWY 31C

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

HINKO ONE

LAUGHLIN ONE

Airport Diagram

Download PDF - 0901Z 02/25/21

Need a New T-Shirt?

Distance To

Nearby Airports

	Bertani Ranch	5.0 NM
	23TS	NNE 28°
	Del Rio Intl	9.0 NM
	KDRT	W 276°
	La Fonda Ranch	13.8 NM
	2TX3	SE 135°
	Frerich Ranch	15.3 NM
	73TX	SSE 147°
	Horn Ranch	15.9 NM
	4T1	NE 37°
	CIUDAD ACUNA INTL NEW	19.5 NM
	MMCC	W 264°
	Fort Clark Springs	21.3 NM
	74TX	ESE 103°
