This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KIABMc Connell Afb

Private use. Permission required prior to landing.

McConnell AFB, Kansas, United States (67221)

Radio Freq.

Runways

Charts

Lat/Lng:	37° 37' 23.22" N / 97° 16' 3.47" W 37.623117 / -97.267631
Elevation:	1371'ft / 418mMSL
Declination:	E004°
ID / ICAO:	KIAB
FAA:	IAB
Runways:	2
Longest:	01R-19L Asphalt 3,669m / 12,038ft

Airport use:	Military, Private, Permission required
Controlled:	Yes

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

ATIS:	124.65
Ground:	118
Tower:	127.25
Approach:	120.6, 126.7, 127.25, 134.8
Departure:	120.6, 124.75, 134.8

[ Edit disabled ]

Nearby VORs <50NM

WICHITA VORTAC		19.2 NM
ICT	freq: 113.80	NW 296°
HUTCHINSON VOR-DME		44.6 NM
HUT	116.80	NW 305°

Nearby NDBs

PICHE NDB		10.8 NM
IC	freq: 332	W 253°
WELLINGTON NDB		21.8 NM
EGT	414	S 197°
NEWTON NDB		30.5 NM
EWK	281	N 359°
HARVS NDB		36.1 NM
CA	395	N 359°
SAWCY NDB		39.0 NM
SO	353	S 160°
SALTT NDB		49.9 NM
HU	404	NW 313°

Runway 01L / 19R

Dimensions:	3653.2 x 61m 11986' x 200'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 01L [A]	Runway 19R [B]
Heading:	008°MH 012°TH	188°MH 192°TH
Lat: Lng:	37° 36' 26.18"N 97° 16' 24.58"W	37° 38' 22.02"N 97° 15' 52.37"W
ALS:	ALSF-I	ALSF-I
TDZ:	Yes, lighted

[ Edit disabled ]

Runway 01R / 19L

Dimensions:	3669.3 x 91.4m 12038' x 300'ft
Surface:	Asphalt
Edge Lights:	High intensity

	Runway 01R [A]	Runway 19L [B]
Heading:	008°MH 012°TH	188°MH 192°TH
Lat: Lng:	37° 36' 24.42"N 97° 16' 14.56"W	37° 38' 20.29"N 97° 15' 42.33"W
ALS:	SSALR	ALSF-I

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

ILS OR LOC RWY 01L	ILS OR LOC RWY 19R	RNAV (GPS) RWY 01L	RNAV (GPS) RWY 01R	RNAV (GPS) RWY 19L
RNAV (GPS) RWY 19R	TACAN RWY 01L	TACAN RWY 01R	TACAN RWY 19L	TACAN RWY 19R

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

Airport Diagram

Download PDF - 0901Z 02/25/21

Need a New T-Shirt?

Distance To

Nearby Airports

	Cessna Acft Field	2.0 NM
	KCEA	NNE 27°
	Beyer Farm	2.8 NM
	K14	SSE 163°
	Hamilton Field	4.7 NM
	1K3	SSE 156°
	Westport Auxiliary	5.2 NM
	72K	WSW 255°
	Beech Factory	5.7 NM
	KBEC	NNE 30°
	Vankirk	5.8 NM
	44KS	E 98°
	Cook Airfield	6.4 NM
	K50	SE 127°
