This page is community maintained. The information is intended for PC simulator navigation or reference. Always use approved charts for navigation.
Elkhart, Indiana, United States (46514)
Lat/Lng: | 41° 43' 9.86" N / 86° 0' 11.59" W
41.719406 / -86.003219 |
---|
Elevation: | 778'ft / 237mMSL |
---|
Declination: | W004° | ID / ICAO: | KEKM |
---|
FAA: | EKM |
---|
Runways: | 3 |
---|
Longest: | 09-27 Asphalt 1,980m / 6,494ft |
---|
| |
---|
Controlled: | Yes |
---|
(Edited 2014-05-21) [ Edit disabled ]
AWOS 3: | 124.47 |
---|
CTAF: | 119.5 |
---|
UNICOM: | 122.95 |
---|
Clearance Delivery: | 121.8 |
---|
Ground: | 121.8 |
---|
Tower: | 119.5 |
---|
Approach: | 118.55 |
[ Edit disabled ]
GOSHEN VORTAC | 13.5 NM |
GSH | freq: 113.70 |
S 185° |
GIPPER VORTAC | 16.6 NM |
GIJ | 115.40 |
W 281° |
KEELER VOR-DME | 30.0 NM |
ELX | 116.60 |
N 348° |
WEBSTER LAKE VOR | 41.8 NM |
OLK | 110.40 |
SE 141° |
KALAMAZOO VOR-DME | 42.6 NM |
AZO | 109.00 |
NE 32° |
KNOX VOR-DME | 43.3 NM |
OXI | 115.60 |
SW 230° |
|
MISHA NDB | 11.2 NM |
SB | freq: 341 |
W 265° |
THREE RIVERS NDB | 26.9 NM |
HAI | 407 |
NE 52° |
STURGIS NDB | 30.1 NM |
IRS | 382 |
E 77° |
MALLY NDB | 32.3 NM |
BE | 397 |
NW 330° |
AUSTN NDB | 37.4 NM |
AZ | 371 |
NE 40° |
CULVER NDB | 40.0 NM |
CPB | 391 |
SW 209° |
LA PORTE NDB | 42.5 NM |
IUL | 356 |
W 248° |
ANGOLA NDB | 47.6 NM |
ANQ | 347 |
E 96° |
SEDLY NDB | 48.8 NM |
VP | 212 |
SW 247° |
|
Dimensions: | 1979.5 x 36.6m 6494' x 120'ft |
Surface: | Asphalt |
---|
Edge Lights: | High intensity |
---|
| Runway 09 [A] | Runway 27 [B] |
Heading: | 093°MH 089°TH | 273°MH 269°TH |
---|
Lat: Lng: | 41° 43' 15.25"N 86° 1' 9.81"W | 41° 43' 15.37"N 85° 59' 44.1"W |
---|
ALS: | | MALSR |
Dimensions: | 1223.1 x 22.9m 4013' x 75'ft |
Surface: | Asphalt |
---|
Edge Lights: | Medium intensity |
---|
| Runway 18 [A] | Runway 36 [B] |
Heading: | 175°MH 171°TH | 355°MH 351°TH |
---|
Lat: Lng: | 41° 43' 20.12"N 85° 59' 35.81"W | 41° 42' 40.99"N 85° 59' 28.42"W |
---|
TDZ: | | Yes, lighted |
Dimensions: | 756.4 x 30.5m 2482' x 100'ft |
Surface: | Dirt |
---|
| Runway 08 [A] | Runway 26 [B] |
Heading: | 079°MH 075°TH | 259°MH 255°TH |
---|
Lat: Lng: | 41° 43' 6.81"N 86° 0' 27.63"W | 41° 43' 12.97"N 85° 59' 55.61"W |
|
