This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KPITPittsburgh Intl

Pittsburgh, Pennsylvania, United States (15126)

(C)

Radio Freq.

Runways

Charts

Lat/Lng:	40° 29' 29.07" N / 80° 13' 57.7" W 40.491408 / -80.232694
Elevation:	1203'ft / 367mMSL
Declination:	W008°
ID / ICAO:	KPIT
FAA:	PIT
Runways:	4
Longest:	10R-28L Concrete 3,492m / 11,458ft

Controlled:	Yes

(Edited 2013-07-28) [ Edit disabled ]

Airport Radio Frequencies

Ground:	130.77, 131.37
Tower:	135.02
Approach:	120.87, 123.95, 124.15
Departure:	127.95

[ Edit disabled ]

Nearby VORs <50NM

MONTOUR VORTAC		2.1 NM
MMJ	freq: 112.00	E 96°
ALLEGHENY VOR-DME		17.8 NM
AGC	110.00	SE 145°
ELLWOOD CITY VORTAC		23.1 NM
EWC	115.80	N 2°
WHEELING VOR-DME		23.8 NM
HLG	112.20	SW 227°
BELLAIRE VOR-DME		45.0 NM
AIR	117.10	SW 223°

Nearby NDBs

MC KEESPORT NDB		25.6 NM
MKP	freq: 287	E 111°
DORCH (OM) NDB		35.7 NM
HL	212	SW 222°
CASTLE NDB		38.0 NM
UCP	272	N 345°
TOLSON NDB		44.6 NM
TSO	395	W 276°
CADIZ NDB		44.7 NM
CFX	239	SW 246°
HUBBARD NDB		48.3 NM
HBD	408	N 341°
CAMOR NDB		49.3 NM
VV	299	SE 148°

Runway 10R / 28L

Dimensions:	3492.3 x 61m 11458' x 200'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 10R [A]	Runway 28L [B]
Heading:	099°MH 091°TH	279°MH 271°TH
Lat: Lng:	40° 29' 12.22"N 80° 15' 6.87"W	40° 29' 8.31"N 80° 12' 38.14"W
ALS:	ALSF-II	SALS
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 10L / 28R

Dimensions:	3186.5 x 46m 10454' x 151'ft
Surface:	Asphalt
Edge Lights:	Medium intensity

	Runway 10L [A]	Runway 28R [B]
Heading:	099°MH 091°TH	279°MH 271°TH
Lat: Lng:	40° 30' 8.41"N 80° 16' 16.27"W	40° 30' 4.87"N 80° 14' 0.4"W
ALS:	ALSF-II	SALS
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 10C / 28C

Dimensions:	2945.1 x 46m 9662' x 151'ft
Surface:	Asphalt
Edge Lights:	Medium intensity

	Runway 10C [A]	Runway 28C [B]
Heading:	099°MH 091°TH	279°MH 271°TH
Lat: Lng:	40° 29' 23.55"N 80° 14' 46.54"W	40° 29' 20.25"N 80° 12' 40.97"W
TDZ:		Yes, lighted

[ Edit disabled ]

Runway 14 / 32

Dimensions:	2462.3 x 46m 8078' x 151'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 14 [A]	Runway 32 [B]
Heading:	144°MH 136°TH	324°MH 316°TH
Lat: Lng:	40° 29' 45.66"N 80° 13' 29.53"W	40° 28' 47.7"N 80° 12' 17.21"W
ALS:		SSALF
TDZ:		Yes, lighted

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

ALTERNATE MINIMUMS

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

PITTSBURGH FIVE

Airport Diagram

Download PDF - 0901Z 02/25/21

Need a New T-Shirt?

Distance To

Nearby Airports

	Lenzner Farm	6.9 NM
	7PS7	ENE 61°
	Frame Fld	7.6 NM
	82PA	SSW 210°
	Cataney	8.8 NM
	PN62	SSW 203°
	Mc Coy	10.0 NM
	88PA	WNW 289°
	Miller	11.0 NM
	P64	WSW 257°
	Hanny Beaver Airpark Inc	12.1 NM
	80PN	WNW 286°
	Kindelberger Landing Strip	14.1 NM
	24PA	N 11°
