This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KMIBMinot Afb

Private use. Permission required prior to landing.

Minot AFB, North Dakota, United States (58704)

Radio Freq.

Runways

Charts

Lat/Lng:	48° 24' 56.77" N / 101° 21' 28.94" W 48.415769 / -101.358039
Elevation:	1667'ft / 508mMSL
Declination:	E010°
ID / ICAO:	KMIB
FAA:	MIB
Runways:	1
Longest:	11-29 Concrete 4,007m / 13,147ft

Airport use:	Military, Private, Permission required
Controlled:	Yes

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

Ground:	134
Tower:	120.65
Approach:	119.6
Departure:	119.6

[ Edit disabled ]

Nearby VORs <50NM

MINOT VORTAC		11.2 NM
MOT	freq: 117.10	S 163°

Nearby NDBs

No NDBs found within 50nm

Runway 11 / 29

Dimensions:	4007.3 x 91.4m 13147' x 300'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 11 [A]	Runway 29 [B]
Heading:	115°MH 125°TH	295°MH 305°TH
Lat: Lng:	48° 25' 34.19"N 101° 22' 48.94"W	48° 24' 19.29"N 101° 20' 8.92"W
ALS:	ALSF-I	ALSF-I
TDZ:	Yes, lighted

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

HI-ILS OR LOC Z RWY 12	HI-ILS OR LOC Z RWY 30	ILS OR LOC Y RWY 12	ILS OR LOC Y RWY 30	HI-TACAN Z RWY 12
HI-TACAN Z RWY 30	TACAN Y RWY 12	TACAN Y RWY 30	COPTER RNAV (GPS) RWY 12	COPTER RNAV (GPS) RWY 30
COPTER TACAN 125	COPTER TACAN 292

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

Airport Diagram

Download PDF - 0901Z 02/25/21

Need a New T-Shirt?

Distance To

Nearby Airports

	Jeune Strip	9.0 NM
	2NA1	NNW 336°
	Judy Strip	9.0 NM
	ND18	NE 45°
	Behrens Airstrip	10.1 NM
	NA30	S 190°
	Minot Intl	11.5 NM
	KMOT	SSE 161°
	Millers Airstrip	14.5 NM
	81ND	E 97°
	Flying S Ranch	15.1 NM
	ND43	S 188°
	Hanson Strip	15.2 NM
	5NA7	WNW 283°
