This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KJAXJacksonville Intl

Jacksonville, Florida, United States (32218)

(C)

Radio Freq.

Runways

Charts

Lat/Lng:	30° 29' 38.6" N / 81° 41' 16.2" W 30.494056 / -81.687833
Elevation:	29'ft / 9mMSL
Declination:	W006°
ID / ICAO:	KJAX
FAA:	JAX
Runways:	2
Longest:	07-25 Concrete 3,042m / 9,979ft

Controlled:	Yes
Beacon:	White-Green

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

ATIS:	125.85
UNICOM:	122.95
Clearance Delivery:	119.5
Ground:	121.9
Tower:	118.3
Approach:	118, 118.6, 119, 121.3

[ Edit disabled ]

Nearby VORs <50NM

CRAIG VORTAC		15.1 NM
CRG	freq: 114.50	SE 135°
CECIL VOR		22.9 NM
VQQ	117.90	SW 211°
BRUNSWICK VORTAC		41.0 NM
SSI	109.80	N 20°
ST AUGUSTINE VOR-DME		42.8 NM
SGJ	109.40	SE 150°

Nearby NDBs

EASTPORT NDB		6.7 NM
EYA	freq: 357	SE 136°
DINNS (LOM/NDB) NDB		7.1 NM
JA	344	W 253°

Runway 07 / 25

Dimensions:	3041.7 x 45.7m 9979' x 150'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 07 [A]	Runway 25 [B]
Heading:	076°MH 070°TH	256°MH 250°TH
Lat: Lng:	30° 29' 46.38"N 81° 41' 59.88"W	30° 30' 19.34"N 81° 40' 12.1"W
ALS:	ALSF-II	MALSR
TDZ:	Yes

[ Edit disabled ]

Runway 13 / 31

Dimensions:	2349.6 x 45.7m 7709' x 150'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 13 [A]	Runway 31 [B]
Heading:	136°MH 130°TH	316°MH 310°TH
Lat: Lng:	30° 29' 31.78"N 81° 42' 3.01"W	30° 28' 42.24"N 81° 40' 56.13"W
ALS:	MALSR
TDZ:		Yes, lighted

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

ALTERNATE MINIMUMS

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

ALMA TWO	HOTAR ONE (RNAV)	LUNNI ONE (RNAV)	MARQO TWO (RNAV)	OHDEA ONE (RNAV)
OHDEA ONE (RNAV), CONT.1	POGIE TWO	QUBEN ONE (RNAV)	QUBEN ONE (RNAV), CONT.1	TEBOW ONE (RNAV)
TEBOW ONE (RNAV), CONT.1

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

HI-ILS OR LOC RWY 08	HI-ILS OR LOC RWY 14	HI-ILS OR LOC RWY 26	ILS OR LOC RWY 08	ILS OR LOC RWY 14
ILS OR LOC RWY 26	ILS RWY 08 (SA CAT I)	ILS RWY 08 (CAT II - III)	RNAV (RNP) Y RWY 08	RNAV (RNP) Y RWY 14
RNAV (RNP) Y RWY 26	RNAV (RNP) Y RWY 32	RNAV (GPS) Z RWY 08	RNAV (GPS) Z RWY 14	RNAV (GPS) Z RWY 26
RNAV (GPS) Z RWY 32	VOR/DME RWY 32	HI-TACAN RWY 14

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

ARNEY TWO (RNAV)	CROSB TWO (RNAV)	EXBOX TWO (RNAV)	JACKSONVILLE SEVEN	JETIN TWO (RNAV)
SAWGY TWO

Airport Diagram

Download PDF - 0901Z 02/25/21

Need a New T-Shirt?

Distance To

Nearby Airports

	Baine	3.6 NM
	FL20	NE 51°
	Flying-A-Ranch	10.2 NM
	62J	NE 43°
	Nassau	12.6 NM
	83FL	NE 46°
	Whitehouse Nolf	14.6 NM
	KNEN	SW 226°
	Jacksonville Executive At Crai	15.0 NM
	KCRG	SE 136°
	Fernandina Beach Muni	15.7 NM
	KFHB	ENE 58°
	Herlong Recreational	16.5 NM
	KHEG	SSW 205°
