This page is community maintained. The information is intended for PC simulator navigation or reference.
Always use approved charts for navigation.

KDTWDetroit Metropolitan Wayne Cou

Detroit, Michigan, United States (48242)

(C)

Radio Freq.

Runways

Charts

Lat/Lng:	42° 12' 44.7" N / 83° 21' 12.2" W 42.212417 / -83.353389
Elevation:	645'ft / 197mMSL
Declination:	W006°
ID / ICAO:	KDTW
FAA:	DTW
Runways:	6
Longest:	04R-22L Concrete 3,653m / 11,986ft

Controlled:	Yes

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

ATIS:	133.67
UNICOM:	122.95
Clearance Delivery:	120.65
Ground:	119.25, 119.45, 121.8, 132.72
Tower:	118.4, 135
Approach:	118.57, 124.05, 125.15
Departure:	118.57, 118.95, 125.52, 132.02

[ Edit disabled ]

Nearby VORs <50NM

DETROIT VOR-DME		0.7 NM
DXO	freq: 113.40	W 274°
CARLETON VORTAC		12.5 NM
CRL	115.70	SW 205°
SALEM VORTAC		18.3 NM
SVM	114.30	NW 317°
WINDSOR VOR-DME		27.0 NM
YQG	113.80	E 84°
PONTIAC VORTAC		35.0 NM
PSI	111.00	N 344°

Nearby NDBs

REVUP NDB		7.5 NM
DT	freq: 388	SW 212°
SPENC NDB		7.7 NM
DM	223	E 86°
GROSSE ILE NDB		12.8 NM
RYS	419	SE 126°
YIPPS NDB		14.0 NM
YI	359	W 259°
LAUREL NDB		15.8 NM
ZQG	398	E 82°
CARGL NDB		22.7 NM
VQ	230	NE 64°
MADDS (LOM) NDB		23.6 NM
DE	338	NE 34°
WINDSOR NDB		25.7 NM
QG	353	E 74°
TECUMSEH NDB		30.0 NM
TCU	239	SW 245°
BERZ NDB		36.8 NM
UIZ	215	NE 32°
HOWELL NDB		43.3 NM
OZW	243	NW 312°
ADRIAN NDB		44.0 NM
ADG	278	SW 237°
PELEE ISLAND NDB		46.1 NM
PT	283	SE 130°

Runway 04R / 22L

Dimensions:	3653.2 x 61m 11986' x 200'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 04R [A]	Runway 22L [B]
Heading:	034°MH 028°TH	214°MH 208°TH
Lat: Lng:	42° 12' 8.37"N 83° 22' 16.57"W	42° 13' 52.37"N 83° 20' 59.97"W
ALS:	ALSF-II	SALS
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 03R / 21L

Dimensions:	3041.7 x 46m 9979' x 151'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 03R [A]	Runway 21L [B]
Heading:	034°MH 028°TH	214°MH 208°TH
Lat: Lng:	42° 11' 44.21"N 83° 21' 6.49"W	42° 13' 10.86"N 83° 20' 2.65"W
ALS:	ALSF-II	SALS
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 04L / 22R

Dimensions:	3041.7 x 46m 9979' x 151'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 04L [A]	Runway 22R [B]
Heading:	034°MH 028°TH	214°MH 208°TH
Lat: Lng:	42° 12' 7.82"N 83° 23' 2.4"W	42° 13' 34.48"N 83° 21' 58.61"W
ALS:	ALSF-II	SALS
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 09L / 27R

Dimensions:	2639.3 x 61m 8659' x 200'ft
Surface:	Asphalt
Edge Lights:	Medium intensity

	Runway 09L [A]	Runway 27R [B]
Heading:	094°MH 088°TH	274°MH 268°TH
Lat: Lng:	42° 13' 1.08"N 83° 21' 47.4"W	42° 13' 3.03"N 83° 19' 51.71"W
ALS:		SALS

[ Edit disabled ]

Runway 03L / 21R

Dimensions:	2591 x 61m 8501' x 200'ft
Surface:	Asphalt
Edge Lights:	Medium intensity

	Runway 03L [A]	Runway 21R [B]
Heading:	034°MH 028°TH	214°MH 208°TH
Lat: Lng:	42° 12' 28.2"N 83° 21' 4.38"W	42° 13' 41.85"N 83° 20' 10.11"W
TDZ:		Yes, lighted

[ Edit disabled ]

Runway 09R / 27L

Dimensions:	2574.9 x 46m 8448' x 151'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 09R [A]	Runway 27L [B]
Heading:	094°MH 088°TH	274°MH 268°TH
Lat: Lng:	42° 11' 56.46"N 83° 21' 42.22"W	42° 11' 58.34"N 83° 19' 49.33"W
ALS:		SALS
TDZ:		Yes, lighted

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

HOT SPOT

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

ILS OR LOC RWY 03R	ILS OR LOC RWY 04R	ILS OR LOC RWY 21L	ILS OR LOC RWY 22L	ILS OR LOC RWY 27L
ILS OR LOC RWY 27R	ILS Z OR LOC RWY 04L	ILS Z OR LOC RWY 22R	ILS Y RWY 04L	ILS Y RWY 22R
ILS RWY 03R (SA CAT I)	ILS RWY 04R (SA CAT I)	ILS RWY 21L (SA CAT I - II)	ILS RWY 22L (SA CAT I)	ILS RWY 27L (SA CAT I - II)
ILS Z RWY 22R (SA CAT I - II)	ILS RWY 03R (CAT II - III)	ILS RWY 04R (CAT II - III)	ILS Z RWY 04L (CAT II - III)	RNAV (RNP) U RWY 04L
RNAV (RNP) U RWY 22R	RNAV (RNP) W RWY 03R	RNAV (RNP) W RWY 04L	RNAV (RNP) W RWY 21L	RNAV (RNP) W RWY 22R
RNAV (RNP) X RWY 03R	RNAV (RNP) X RWY 04L	RNAV (RNP) X RWY 04R	RNAV (RNP) X RWY 21L	RNAV (RNP) X RWY 22L
RNAV (RNP) X RWY 22R	RNAV (GPS) RWY 27L	RNAV (GPS) RWY 27R	RNAV (GPS) Y RWY 04L	RNAV (GPS) Y RWY 22R
RNAV (GPS) Z RWY 03R	RNAV (GPS) Z RWY 04L	RNAV (GPS) Z RWY 04R	RNAV (GPS) Z RWY 21L	RNAV (GPS) Z RWY 22L
RNAV (GPS) Z RWY 22R	PRM AAUP	ILS PRM RWY 04R	ILS PRM RWY 22L	ILS PRM Y RWY 04L
ILS PRM Y RWY 22R	ILS PRM Z RWY 04L	ILS PRM Z RWY 22R	ILS PRM RWY 04R (SA CAT I)	ILS PRM Z RWY 22R (SA CAT I - II)
ILS PRM RWY 04R (CAT II - III)	ILS PRM Z RWY 04L (CAT II - III)	RNAV (GPS) PRM Y RWY 04L	RNAV (GPS) PRM Y RWY 22R	RNAV (GPS) PRM Z RWY 04R
RNAV (GPS) PRM Z RWY 22L

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

Airport Diagram

Download PDF - 0901Z 02/25/21
