KDFWDallas/fort Worth Intl

Grapevine, Texas, United States (76051)

(C)

Radio Freq.

Runways

Charts

Lat/Lng:	32° 53' 48.58" N / 97° 2' 16.79" W 32.896828 / -97.037997
Elevation:	607'ft / 185mMSL
Declination:	E006°
ID / ICAO:	KDFW
FAA:	DFW
Runways:	7
Longest:	17C-35C Concrete 4,088m / 13,411ft

Controlled:	Yes
Beacon:	White-Green

(Edited 2014-05-21) [ Edit disabled ]

Airport Radio Frequencies

ATIS Arrival:	123.77
ATIS Departure:	135.92
UNICOM:	122.95
Clearance Delivery:	128.25
Ground:	121.65, 121.8, 121.85
Tower:	124.15, 126.55, 127.5, 134.9
Approach:	119.87, 125.02, 133.52, 133.62
Departure:	118.55, 124.82, 125.12, 126.47

[ Edit disabled ]

Nearby VORs <50NM

MAVERICK VOR-DME		1.9 NM
TTT	freq: 113.10	S 184°
COWBOY VOR-DME		7.8 NM
CVE	116.20	E 93°
RANGER VORTAC		8.2 NM
FUZ	115.70	W 266°

Nearby NDBs

ISSUE NDB		6.6 NM
PK	freq: 233	S 174°
JIFFY NDB		6.9 NM
FL	219	N 4°
CONIS NDB		17.4 NM
LV	275	SE 118°
REDBIRD NDB		18.0 NM
RBD	287	SE 147°
MUFIN NDB		19.5 NM
FT	365	W 269°
PINCK NDB		28.2 NM
DT	257	N 341°
MESQUITE NDB		30.1 NM
PQF	248	E 101°
JECCA NDB		33.4 NM
JUG	388	SE 118°
FLUET NDB		36.2 NM
EF	421	NE 45°
TRAVIS NDB		46.8 NM
AVZ	260	E 101°
CADDO MILLS NDB		46.8 NM
MII	316	E 77°

Runway 17C / 35C

Dimensions:	4087.7 x 46m 13411' x 151'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 17C [A]	Runway 35C [B]
Heading:	174°MH 180°TH	354°MH 000°TH
Lat: Lng:	32° 54' 56.59"N 97° 1' 33.49"W	32° 52' 44"N 97° 1' 34.22"W
ALS:	ALSF-II	ALSF-II
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 17L / 35R

Dimensions:	2591 x 46m 8501' x 151'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 17L [A]	Runway 35R [B]
Heading:	174°MH 180°TH	354°MH 000°TH
Lat: Lng:	32° 53' 54"N 97° 0' 35.2"W	32° 52' 29.89"N 97° 0' 35.67"W
ALS:	ALSF-II	ALSF-II
TDZ:	Yes

[ Edit disabled ]

Runway 18R / 36L

Dimensions:	4087.7 x 46m 13411' x 151'ft
Surface:	Concrete
Edge Lights:	Medium intensity

	Runway 18R [A]	Runway 36L [B]
Heading:	174°MH 180°TH	354°MH 000°TH
Lat: Lng:	32° 54' 56.93"N 97° 3' 16.71"W	32° 52' 44.35"N 97° 3' 17.4"W
ALS:	ALSF-II	MALSR
TDZ:	Yes	Yes, lighted

[ Edit disabled ]

Runway 17R / 35L

Dimensions:	4087.7 x 61m 13411' x 200'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 17R [A]	Runway 35L [B]
Heading:	174°MH 180°TH	354°MH 000°TH
Lat: Lng:	32° 54' 56.64"N 97° 1' 47.58"W	32° 52' 44.06"N 97° 1' 48.29"W
ALS:	MALSR	MALSR
TDZ:		Yes, lighted

[ Edit disabled ]

Runway 18L / 36R

Dimensions:	4087.7 x 61m 13411' x 200'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 18L [A]	Runway 36R [B]
Heading:	174°MH 180°TH	354°MH 000°TH
Lat: Lng:	32° 54' 56.88"N 97° 3' 2.65"W	32° 52' 44.3"N 97° 3' 3.33"W
ALS:	MALSR	MALSR

[ Edit disabled ]

Runway 13R / 31L

Dimensions:	2832.4 x 46m 9293' x 151'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 13R [A]	Runway 31L [B]
Heading:	133°MH 139°TH	313°MH 319°TH
Lat: Lng:	32° 54' 34.52"N 97° 4' 59.28"W	32° 53' 25.01"N 97° 3' 47.79"W
ALS:	MALSR
TDZ:		Yes

[ Edit disabled ]

Runway 13L / 31R

Dimensions:	2735.9 x 61m 8976' x 200'ft
Surface:	Concrete
Edge Lights:	High intensity

	Runway 13L [A]	Runway 31R [B]
Heading:	129°MH 135°TH	309°MH 315°TH
Lat: Lng:	32° 54' 45.24"N 97° 1' 17.32"W	32° 53' 41.97"N 97° 0' 3.04"W
ALS:		MALSR

[ Edit disabled ]

User Notes and Comments

Ad:

Airport Charts[S:2102] 0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AIRPORT DIAGRAM

TAKEOFF MINIMUMS

ALTERNATE MINIMUMS

STAR Charts0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

(IAP) Instrument Approach Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

ILS OR LOC RWY 13R	ILS OR LOC RWY 17C	ILS OR LOC RWY 17L	ILS OR LOC RWY 17R	ILS OR LOC RWY 18L
ILS OR LOC RWY 18R	ILS OR LOC RWY 31R	ILS OR LOC RWY 35C	ILS OR LOC RWY 35L	ILS OR LOC RWY 35R
ILS OR LOC RWY 36L	ILS OR LOC RWY 36R	ILS RWY 17C (SA CAT I)	ILS RWY 17L (SA CAT I)	ILS RWY 18R (SA CAT I)
ILS RWY 35C (SA CAT I)	ILS RWY 35R (SA CAT I)	ILS RWY 13R (SA CAT I - II)	ILS RWY 17R (SA CAT I - II)	ILS RWY 31R (SA CAT I - II)
ILS RWY 17C (CAT II - III)	ILS RWY 17L (CAT II - III)	ILS RWY 18R (CAT II - III)	ILS RWY 35C (CAT II - III)	ILS RWY 35R (CAT II - III)
ILS RWY 36L (SA CAT II)	CONVERGING ILS RWY 13R	CONVERGING ILS RWY 17C	CONVERGING ILS RWY 17R	CONVERGING ILS RWY 18L
CONVERGING ILS RWY 18R	CONVERGING ILS RWY 31R	CONVERGING ILS RWY 35C	CONVERGING ILS RWY 35L	CONVERGING ILS RWY 36L
CONVERGING ILS RWY 36R	RNAV (RNP) Z RWY 13R	RNAV (RNP) Z RWY 31L	RNAV (RNP) Z RWY 31R	RNAV (GPS) RWY 17C
RNAV (GPS) RWY 17L	RNAV (GPS) RWY 17R	RNAV (GPS) RWY 18L	RNAV (GPS) RWY 18R	RNAV (GPS) RWY 35C
RNAV (GPS) RWY 35L	RNAV (GPS) RWY 35R	RNAV (GPS) RWY 36L	RNAV (GPS) RWY 36R	RNAV (GPS) Y RWY 13R
RNAV (GPS) Y RWY 31L	RNAV (GPS) Y RWY 31R

Departure Procedures0901Z 02/25/21 - 0901Z 03/25/21 d -TPP

AKUNA NINE (RNAV)	AKUNA NINE (RNAV), CONT.1	ALIAN TWO (RNAV)	ALIAN TWO (RNAV), CONT.1	ARDIA SEVEN (RNAV)
ARDIA SEVEN (RNAV), CONT.1	BLECO EIGHT (RNAV)	BLECO EIGHT (RNAV), CONT.1	COYOTE TWO	COYOTE TWO, CONT.1
DALLAS SEVEN	DALLAS SEVEN, CONT.1	DARTZ EIGHT (RNAV)	DARTZ EIGHT (RNAV), CONT.1	FORCK TWO (RNAV)
FORCK TWO (RNAV), CONT.1	GARLAND NINE	GARLAND NINE, CONT.1	GRABE EIGHT (RNAV)	GRABE EIGHT (RNAV), CONT.1
HRPER THREE (RNAV)	HRPER THREE (RNAV), CONT.1	HUDAD TWO (RNAV)	HUDAD TWO (RNAV), CONT.1	JACKY SEVEN
JASPA SIX (RNAV)	JASPA SIX (RNAV), CONT.1	JOE POOL TWO	JOE POOL TWO, CONT.1	KATZZ TWO (RNAV)
KATZZ TWO (RNAV), CONT.1	KEENE TWO	KINGDOM EIGHT	KINGDOM EIGHT, CONT.1	KUSSO SEVEN (RNAV)
KUSSO SEVEN (RNAV), CONT.1	LOWGN EIGHT (RNAV)	LOWGN EIGHT (RNAV), CONT.1	MRSSH TWO (RNAV)	MRSSH TWO (RNAV), CONT.1
NELYN SIX (RNAV)	NELYN SIX (RNAV), CONT.1	SWABR SEVEN (RNAV)	SWABR SEVEN (RNAV), CONT.1	TEXOMA NINE
TEXOMA NINE, CONT.1	TRI-GATE THREE	TRYTN THREE (RNAV)	TRYTN THREE (RNAV), CONT.1	WORTH FIVE
WORTH FIVE, CONT.1	WSTEX TWO (RNAV)	WSTEX TWO (RNAV), CONT.1	ZACHH THREE (RNAV)	ZACHH THREE (RNAV), CONT.1

Airport Diagram
